Mesin Raja CGF14-12-5 Talian Pengeluaran Air 3000bph
1, Rated capacity: 500ml 3000BPH2, Filling material: Pure water3, Filling type: Gravity filling, normal temperature4, Filling container : PET bottle, within 2L5, Cap: Plastic screw cap6, Label: PVC shrink sleeve label7, Package: PE Film package8, Bottle blowing machine: KM-SA49, Injection molding machine:/10,Power generator:/11,Conveyor mode: air conveyor flat conveyor12,Rated power: 100KW, normal use 40-50KW13,Workers: 10 workers14,Area: 200m2 (final layout drawing is based on customer's workshop)15,Condition: Temperature: 10-40 degree Humidity: no dew ( Less than or equal to 95％)
pengenalan produk
Tidak | Nama peralatan | Parameter teknikal | Kuantiti | harga |
1 | penghantar udara | 1, Model: FS-I 2, Bahan: Keluli tahan karat SUS304, dibuat di china 3, Panjang: 3m 4, Manner of bottle inputting: Bottle handling with air delivering. 5, Kuasa motor: 0.75KW | 1 ditetapkan | |
2 | Filling 3-IN-1 machine main body | 1, Model: CGF 14-12-52019 new 2, Number of heads: 14 washing heads, 12 filling heads and 5 capping heads 3, Kapasiti: 3000B/H (500ml botol standard PET) 4, Material: The material which contact directly with the liquid is the SUS304 (Food grade), made in china. The transmission mechanism and the gear are equipped with firing A4 carbon steel. 5, 3-dalam-1 digunakan terutamanya untuk mengisi air. 6, Pelupusan : 6.1,Motor: LICHAO SHANGHAI 6.2,Kotak gear: jenama JIE Hangzhou 6.3,Kawalan kelajuan terbalik:Japanese Mitsubishi 7, Isipadu botol PET : 0.25L-2L 8, Diameter botol: 50-115mm 9, Ketinggian botol: 160-320mm 10, Cap: plastic screw type cap 11, Filling temperature: normal temperature 12, Filling pressure: Gravity filling pressure 13, Filling precision: ±2-3 percent 14, Pressure of washing: 0.2Mpa 15, Washing consuming water: 450kg/h 16, Gas consumption: 0.4m³ /min 17, Main motor power: 3kw 18, Dimension: 240019002200mm 19, Weight: 3000kg | 1 ditetapkan | |
3 | penghantar | 1, Model: US4/18 2, Material: SUS304 Stainless steel 3, Tali pinggang: Plastik kejuruteraan 4, Panjang: Kawalan kelajuan kurang gred 3m 5, Papan rantai: Keluli tahan karat SUS304 6, Dimensi rantai: 8338mm 7, Kuasa: 0.75KW | 1 ditetapkan | |
Teguran | The CGF Series machine contains all above units | |||
Cool tags: mesin raja cgf14-12-5 barisan pengeluaran air 3000bph, China, pengilang, pembekal, kilang, harga, untuk dijual
